Appendix a - general reference, Torque requirements, Appendix a – Rockwell Automation 7763 OneGear MV SMC Flex Solid-State Motor Controller User Manual
Page 39: General reference, Appendix
Rockwell Automation Publication 7760-IN001
B-EN-P - June 2013
37
Appendix
A
General Reference
Torque Requirements
The following table contains the recommended torquing values for hardware
required to fasten electrical connections (bus-bus or bus-flexible bus links).
Hardware
Recommended Torque
N•m
ft•lb
M6
6.0
4.4
M8
14.0
11.0
M10
29.0
21.0
M12
50.0
37.0
M16
124.0
91.0
