Rockwell Automation Publication 7760-IN001

B-EN-P - June 2013

5

Chapter

2

Transportation and Handling

Unpacking and Inspecting

Before leaving the factory, the controller has been tested mechanically and
electrically. Immediately upon receiving the controller, remove the packing and
check for possible shipping damage. Report any damage immediately to the
claims office of the carrier.

After unpacking, check the items received against the Bill of Lading to ensure
that the nameplate description of each item agrees with the material ordered.
Inspect the controller for physical damage as stated in the Rockwell Automation
Conditions of Sale.

Remove all packing material, wedges or braces from within the controller. If any
part of the equipment will not be installed when it is unpacked, it should be
stored in a clean dry place. The storage temperature must be between
-20...75 °C(-4...167° F) with a maximum humidity of 95% non-condensing.

The controller sections are shipped on wooden skids bolted to the cabinetry.
Lifting brackets are installed at the top corners of the cabinetry. The controller
sections must be maintained in the upright position during any handling.

Round rollers can be used to assist in moving the equipment to the installation
site. Once at the final site, rollers can be used to place the sections in their desired
position.

IMPORTANT

All claims for breakage and damage, whether concealed or obvious, must be
made to the carrier by the customer as soon as possible after receipt of the
shipment. Rockwell Automation will render reasonable assistance in the
securing of adjustment for such damage claims.

ATTENTION: Ensure that the load rating of all lifting equipment is sufficient to
safely raise the controller sections. Refer to the packing slip for shipping
weights.

ATTENTION: Use either a forklift or the pipe rolling technique for positioning
purposes to ensure that the equipment is not scratched, dented or damaged.
Stabilize the controller during handling to guard against tipping and injury to
personnel.

IMPORTANT

Customer installation duties must be performed correctly. Errors can cause
delays in commissioning or damage to the equipment.
