Install lower bus links in the converter cabinet – Rockwell Automation 7763 OneGear MV SMC Flex Solid-State Motor Controller User Manual
Page 26
24
Rockwell Automation Publication 7760-IN001
B-EN-P - June 2013
Chapter 3
Equipment Installation
Figure 21 - Installation of Power Bus (cutaway view)
Install Lower Bus Links in the Converter Cabinet
The Converter Bus Bushings are to be installed in the lower rear section of the
Power Converter section.
Figure 22 - Installation of Lower Bus Links, Line Side
Bolted Connections
between Power Bus
and vertical bus risers
Bus links
Bus bushings
