Rockwell Automation 7763 OneGear MV SMC Flex Solid-State Motor Controller User Manual
Page 20
18
Rockwell Automation Publication 7760-IN001
B-EN-P - June 2013
Chapter 3
Equipment Installation
Figure 14 - Horizontal Power Bus and Bushing Placement
Depending on which side the converter cabinet will fit up to, the bus should be
flush with the side plate facing the mating side of the adjacent switchgear cabinet.
Figure 15 - Horizontal Power Bus Placement
Lower slots for
1250A bus rating
Power Bus Bushing
Flat side facing out
Power Bus Bushing
Flat Side facing out
Adjacent switchgear cabinet
Power bus flush
with sidesheet
