Preface
Publication 2755-6.5
Read this First
This guide provides the configuration bar codes for the following:
•
Decoded Hand-Held Bar Code Scanner
(Catalog No. 2755-HDG-4)
•
RS-232 Synapse Cables
(Catalog No. 2755-HFC-SR2-01, 2755-HFC-SR3-01)
•
IBM or Compatible Keyboard Wedge Synapse Cables
(Catalog No. 2755-HFC-SP1-01, 2755-HFC-SP2-01)
•
DEC Keyboard Wedge Synapse Cables
(Catalog No. 2755-SV1–01, 2755-SV2-01)
•
Scanner Emulation Synapse Cable
(Catalog No. 2755-HFC-SA1-01)
Configuration Bar Code Symbols
The configuration bar code symbols are all Code 128. The scanner is
always enabled to read Code 128 symbols. Default settings are indicated
by an asterisk.
Indicates this Symbol
is the Default Setting
9600 *
Refer to the user manual for the decoded hand-held scanners
(Publication 2755-6.2) for descriptions of the configuration settings.
