RS-232 Synapse Cable (Communication Setup) 3-2
Publication 2755-6.5
Set RS-232 Synapse Cable Defaults
Scan this label to set the default settings for the RS-232 Synapse cable.
Defaults are indicated with an asterisk.
Set RS-232 Synapse Cable Defaults
Scan this label to set the RS-232 Synapse cable to the default settings
shown below.
Item Default Setting
Code on
Page:
Host Standard RS-232 3-3
Baud Rate 9600 3-4
Parity None 3-5
Check Parity Enabled 3-5
Stop Bits 1 3-6
Data Bits 8 3-6
RTS State Low 3-7
Hardware Handshaking None 3-7
Software Handshaking None 3-8
Beep on BEL Disabled 3-9
Unknown Characters Send Bar Codes With Unknown Characters 3-9
Response Timeout 2 Seconds 3-10
Parameter Set Set #1 3-12
Scan the bar code symbols for the settings you need to change.
