AdaptaScan Pass Through Application E–5
Publication 2755-6.5
AdaptaScan Setup
You may need to configure the AdaptaScan RS-232 port to accept the
scanner data. Refer to the AdaptaScan Reader Programming Software
user manual. Verify that the AdaptaScan serial port is configured as
shown below. All settings use the default values except for the Enable
Pass-Through to DeviceNet check box.
1. Default is Terminal
2. Default is
9600 Baud
4. Defaults are:
No Parity,
8 Data and
1 Stop Bit.
3. Default message
length is 0 (sends all
data regardless of
length).
5. Default is
RS-232 Connection
6. Enable
Pass-Through
