C - slc 5/03, 5/04 controller application – Rockwell Automation 2755 Decoded Hand-Held Scanner User Manual
Page 115
Appendix
C
Publication 2755-6.5
SLC 5/03, 5/04 Controller Application
This appendix describes how to configure and operate the scanner when
connected to an SLC 5/03, 5/04 controller.
!
ATTENTION: Do not install the RS-232 Synapse cable
with power applied to either the Synapse cable or SLC
controller. Failure to follow this caution may result in
damage to the scanner, Synapse cable, or SLC.
For additional reference you should refer to the following publications:
•
Advanced Programming Software (APS) User Manual
•
Advanced Programming Software (APS) Reference Manual
