Scanner Configuration (for Synapse Cables)
1-2
Publication 2755-6.5
Scan These Symbols First
Scan both of these labels in sequence to set the scanner to the default
settings for use with a Synapse cable.
Scan this Symbol First
then
Set Scanner for Synapse Cable Operation
Important: You must then scan the following label to enable Synapse
communications.
Enable Synapse Cable Communication
Also scan the ENABLE SYNAPSE CABLE COMMUNICATION bar
code to change the configuration from AdaptaScan Pass Through to the
Synapse cable configuration.
When the Synapse cable communication is enabled, scan the appropriate
bar codes to configure the scanner. Then, scan the appropriate bar codes
to configure the Synapse cable.
