Read this First P–2
Publication 2755-6.5
How to Use this Guide
The following shows a typical sequence for configuring a scanner.
1. Connect scanner to host and apply power.
AdaptaScan Pass
Through Cable
All Other Cables
2. Configure scanner. What type of cable is
connected to the scanner?
Use Bar Codes in Chapter 2
Configuring Scanner (AdaptaScan Cable)
Use Bar Codes in Chapter 1
Configuring Scanner (Synapse Cable)
3. Configure communications. Is the scanner
connected to an Allen-Bradley host device?
Yes
No
Refer to Application Specific Setups:
Enhanced Decoder, refer to Appendix A
Flexible Interface (RB) Module, refer to Appendix B
SLC Processor, refer to Appendix C
PLC Processor, refer to Appendix D
AdaptaScan Pass Through, refer to Appendix E
DTAM Plus DeviceNet, refer to Appendix F
Scan setup codes for cable:
RS–232 Synapse Cable, refer to Chapter 3
IBM PC Wedge Cable, refer to Chapter 4
DEC VT520 Wedge Cable, refer to Chapter 5
DEC VT220/320/420 Wedge Cable, refer to Chapter 6
Scanner Emulation Cable, refer to Chapter 7
4. Scanner is ready for operation. Use the test codes
found on the inside back cover of this guide.
