SLC 5/03, 5/04 Controller Application

C–3

Publication 2755-6.5

Configuration Codes for SLC Application

1. After making the necessary connections, scan the following symbols

to set up the scanner for use with the scanner emulation cable.

Scan this Symbol First

then

Set Scanner for Synapse Cable Operation

then

Enable Synapse Cable Communication

2. Set the bar code suffix to CR LF (ASCII equivalent 7013) by

scanning the following labels.

Suffix
