Chapter
2
Publication 2755-6.5
Scanner Configuration (for
AdaptaScan Pass Through
Cable)
Important:
Use the bar codes in this Chapter to configure the scanner for use with
the AdaptaScan Pass Through Cable:
(Catalog No. 2755-HDC-GA2-08)
Do not use these configuration codes if you are using a Synapse cable.
Refer to section Scanner Configuration for Synapse Cables.
This Chapter also contains the configuration bar codes for the cable
beginning on page 2-25.
Before You Configure the Scanner
Appendix E provides a condensed version of the scanner configuration
and connections that is suitable for many AdaptaScan applications.
Appendix E uses default settings with a few modifications that allow
communications with an AdaptaScan RS-232 port. Appendix E does not
provide codes for all of the options listed in this chapter. An optional
method of configuring the scanner is to use the configuration codes in
Appendix E and then scan the codes (in this chapter) for items you want
to change.
Refer to Appendix E before you begin to determine if the condensed
version of the configuration meets your application’s requirements.
