Rockwell Automation 2755 Decoded Hand-Held Scanner User Manual
Page 107
A–6
Enhanced Decoder Application
Publication 2755-6.5
Configuration Codes for AUX Port Pass Through
1. After making the necessary connections, scan the following following
bar code symbols to setup the scanner for use with the scanner
emulation cable.
Scan this Symbol First
then
Set Scanner for Synapse Cable Operation
Enable Synapse Cable Communication
2. Scan this symbol to set the default settings for the RS-232 synapse
cable.
Set RS-232 Synapse Cable Defaults
3. Set No Parity.
Do Not Check Parity
