AdaptaScan Pass Through Application
E–3
Publication 2755-6.5
Configuration Codes for AdaptaScan Pass Through Application
1. After making the necessary connections, scan the following following
bar code symbols to setup the scanner for use with the scanner
emulation cable.
Scan this Symbol First
then
Set Scanner for AdaptaScan Pass Through Cable Operation
Enable AdaptaScan Pass Through Cable Communications
2. Set No Parity.
Do Not Check Parity
3. Set 8 Data Bits.
8 Data Bits
