1 - scanner configuration (for synapse cables), Important, Scanner configuration (for synapse cables) – Rockwell Automation 2755 Decoded Hand-Held Scanner User Manual
Page 12
Chapter
1
Publication 2755-6.5
Scanner Configuration (for
Synapse Cables)
Important:
Use the bar codes in this section to configure the scanner for use with
one of the following Synapse cables:
Scanner Emulation Cable (Catalog No. 2755-HFC-SA1-01)
IBM XT/AT Keyboard Wedge (Catalog No. 2755-HFC-SP1-01)
PS/2 Keyboard Wedge (Catalog No. 2755-HFC-SP2-01)
RS-232, 25-pin (Catalog No. 2755-HFC-SR2-01)
RS-232, 9-pin (Catalog No. 2755-HFC-SR3-01)
DEC VT510/520 Keyboard Wedge (Catalog No. 2755-HFC-SV2–01)
DEC VT220/320/420 Keyboard Wedge (Catalog No.
2755-HFC-SV1-01)
Do not use these configuration codes if you are using the scanner with an
AdaptaScan Pass Through Cable (Catalog No. 2755-HDC-GA2–08).
Refer to Chapter 2 Scanner Configuration (for AdaptaScan Pass Through
Cable).
