81 Publication 1794-UM061A-EN-P - July 2006
Chapter
7
Configure your Digital Module on an
EtherNet/IP Network
How to Use This Chapter
This chapter describes how a controller controls distributed I/O over an
EtherNet/IP network. The controller requires a communication module to
connect to the network. Distributed I/O modules require an adapter to
connect to the network.
In this example, we show you how to control FLEX I/O over EtherNet using
RSNetWorx for EtherNet and RSLogix 5000 software.
To control distributed I/O over EtherNet, you must:
• Add local and remote EtherNet communication modules to your
RSLogix 5000 project.
• Add distributed I/O to your RSLogix 5000 project.
• Schedule the EtherNet network via RSNetWorxRSNetWorx for
EtherNet.
• Use the I/O information in RSLogix 5000
You can also validate connections to distributed I/O when controlling it over
EtherNet. This task is particularly useful when one or more of the connections
Topic See Page
How to Use This Chapter 81
Set Up the Hardware 82
Select a Requested Packet Interval (RPI) 82
Select a Communication Format 83
Add Distributed I/O 88
Download the Program to the Controller 89
Access Distributed I/O 91
Determining Required Network Parameters 93
Assigning Network Parameters via the BOOTP/DHCP Utility 94
Using Other Methods to Assign Network Parameters 97
Duplicate IP Address Detection 100
IP Address Swapping 102
