10 Preface
1794–TB2 Cage Clamp Terminal Base 1794-IN092
1794–TB3 Cage Clamp Terminal Base
1794–TB3S Spring Clamp Terminal Base Unit
1794–TB3T Temperature Terminal Base Unit
1794–TB3TS Spring Clamp Temperature Base Unit
1794–TB3G Terminal Base Unit
1794–TB3GS Spring Clamp Terminal Base Unit
1794–TB32 Cage Clamp Terminal Base Unit
1794–TB32S Spring Clamp Terminal Base Unit
1794–TBN Terminal Base Unit
1794–TBNF, Fused Terminal Base Unit
, 1794-TB3GK Conformally Coated Terminal Base Unit
1794-TB3K Conformally Coated Terminal Base Unit
1794-TBNFK Conformally Coated Fused Terminal
Base Unit
1794-TB37DS,
-TB62DS,
TB37EXD4VM8,
-TB37EXD4CM8,
-TB62EXD4X15 D-Shell Terminal Base Units and
Distribution Boards 1794-IN107
1794–CE1, –CE3 Extender Cables 1794–5.12
1794–NM1 Mounting Kit 1794–5.13
1794–PS13 24V dc Power Supply 1794-IN069
1794–PS3 24V dc Power Supply
FLEX Ex
1797–IBN16 See note 16 NAMUR Digital Input Module 1797-5.7
1797–OB4D See note 4 NI, Ex Source Digital Output Module 1797-5.6
1797–IE8, -IE8H See note 8 Input Module 1797-5.5
1797–IE8NF See note 8 Selectable Filter Analog Input Module 1797-5.31
1797–OE8, -OE8H See note Analog 8 Output Module 1797-5.3
1797–IRT8 See note 8 Thermocouple/RTD Input Module 1797-5.4
1797–IJ2 See note 2 Channel Frequency Input Module 1797-5.9
1797–TB3
1797–TB3S Cage Clamp Terminal Base
Spring Clamp Terminal Base 1797-5.1
1797-5.2
Catalog
Number
Voltage Description Publications
Installation
Instructions
User Manual
