5 Publication 1794-UM065B-EN-E - July 2006
Preface
Purpose of This Manual
This manual provides information on installation, setting, and reading your
diagnostics on the 1794-IB16D and the 1794-OB16D Diagnostic modules.
Important Warnings and
Cautions
Obey the following warnings and cautions when installing or using these
modules.
For information on See Chapter
1794 Diagnostic Modules 1
Specific Diagnostic Module 2 or 3
Using Diagnostic Modules in a Remote I/O System 4
Using Diagnostic Modules in a DeviceNet System 5
Using Diagnostic Modules in a ControlNet System 6
Using Diagnostic Modules in an EtherNet /IP System 7
Using the Indicators for Troubleshooting Appendix A
Simplified Schematics for all 1794 Digital Modules Appendix B
ATTENTION
Environment and Enclosure
This equipment is intended for use in a Pollution Degree 2 industrial
environment, in overvoltage Category II applications (as defined in IEC
publication 60664-1), at altitudes up to 2000 meters without derating.
This equipment is considered Group 1, Class A industrial equipment
according to IEC/CISPR Publication 11. Without appropriate
precautions, there may be potential difficulties ensuring
electromagnetic compatibility in other environments due to conducted
as well as radiated disturbance.
This equipment is supplied as open-type equipment. It must be
mounted within an enclosure that is suitably designed for those
specific environmental conditions that will be present and
appropriately designed to prevent personal injury resulting from
accessibility to live parts. The interior of the enclosure must be
accessible only by the use of a tool. Subsequent sections of this
publication may contain additional information regarding specific
enclosure type ratings that are required to comply with certain
product safety certifications.
See NEMA Standards publication 250 and IEC publication 60529, as
applicable, for explanations of the degrees of protection provided by
different types of enclosure. Also, see the appropriate sections in this
publication, as well as Industrial Automation Wiring and Grounding
Guidelines, Allen-Bradley publication 1770-4.1, for additional
installation requirements pertaining to this equipment.
