Load Initial Configuration Values
Chapter 7
7-16
Table 7.A
SetĆoutput Setpoints for Unselected Valves
If the unselected
valve controls
and the unselected
valve type is
and during profile,
valve action is
and during profile,
you require
Then enter
Pressure
UniĆdirectional
Direct acting
Maximum pressure
9999
Pressure
UniĆdirectional
Direct acting
Medium pressure
7500 to 5000
Pressure
UniĆdirectional
Direct acting
Low pressure
5000 to 2500
Pressure
UniĆdirectional
Direct acting
Minimum pressure
0
Pressure
UniĆdirectional
Reverse acting
Maximum pressure
0
Pressure
UniĆdirectional
Reverse acting
Medium pressure
2500 to 5000
Pressure
UniĆdirectional
Reverse acting
Low pressure
5000 to 7500
Flow
UniĆdirectional
Reverse acting
Minimum pressure
9999
Flow
UniĆdirectional
Direct acting
Maximum flow
9999
Flow
UniĆdirectional
Direct acting
Medium flow
7500 to 5000
Flow
UniĆdirectional
Direct acting
Low flow
5000 to 2500
Flow
UniĆdirectional
Direct acting
Minimum flow
0
Flow
UniĆdirectional
Reverse acting
Maximum flow
0
Flow
UniĆdirectional
Reverse acting
Medium flow
2500 to 5000
Flow
UniĆdirectional
Reverse acting
Low flow
5000 to 7500
Flow
UniĆdirectional
Reverse acting
Minimum flow
9999
Flow
BiĆdirectional
Direct acting
Maximum flow
9999
Flow
BiĆdirectional
Direct acting
Medium flow
8750 to 7500
Flow
BiĆdirectional
Direct acting
Low flow
7500 to 6250
Flow
BiĆdirectional
Direct acting
Minimum flow
5000
Flow
BiĆdirectional
Reverse acting
Maximum flow
0
Flow
BiĆdirectional
Reverse acting
Medium flow
1250 to 2500
Flow
BiĆdirectional
Reverse acting
Low flow
2500 to 3750
Flow
BiĆdirectional
Reverse acting
Minimum flow
5000
Important: Valve spanning procedures in chapter 9 require unselected
valves be driven at signal levels representative of a normal production run.
We discuss process considerations that impend changing these values in
chapter 10. Changing these values may require you to re-span your valves.
Record all set-output values for unselected valves in worksheets 7.A – 7.D.
