8ć22, Enter and download your worksheet values – Rockwell Automation 1771-QDC, D17716.5.85(Passport) MNL. PLASTIC MOLDING MODULE User Manual
Page 117
Load Initial Profile Values
Chapter 8
8-22
The valve spanning procedures in chapter 9 require these initial values.
Where required, we help you select correct final values required by your
application in chapter 10. For additional information, refer to the Plastic
Molding Module Reference Manual (publication 1771-6.5.88).
After you determine initial values and record them on Worksheet 8-C, you
are ready to proceed.
1.
Enter all worksheet values into your PLC-5 data table.
Important: Be sure that you have not altered any setpoints, and that you
have entered each and every setpoint exactly as on the worksheet.
2.
Use the procedure described in chapter 4 to download command
blocks to the QDC module. We repeat the PPC block download data.
Block
Block ID
Command Bit
Companion
PPC
15
B21/14
none
3.
Check SYS61 and SYS62 for programming errors. Correct as needed.
Enter and Download your
Worksheet Values
