Programming 4-9
1560E-UM050B-EN-P - June 2013
Soft Start
The following parameters are specifically used to adjust the voltage ramp
supplied to the motor.
Parameter Option
Starting Mode
This must be programmed for Soft Start.
Soft Start
Ramp Time u
This programs the time period that the controller
will ramp the output voltage up to full voltage from
the initial Torque level programmed.
0 to 30 s
Initial Torque
The initial reduced output voltage level for the
voltage ramp to the motor is established and
adjusted with this parameter.
0 to 90% locked rotor torque
Kickstart Time
A boost of current is provided to the motor for the
programmed time period.
0.0 to 2.0 s
Kickstart Level
Adjusts the amount of current applied to the motor
during the kickstart time.
0 to 90/% locked rotor torque
u If the controller senses that the motor has reached full speed before completing the Soft Start, it
will automatically switch to providing full voltage to the motor.
Current Limit Start
To apply a fixed, reduced-output voltage to the motor, the following
parameters are provided for user adjustment:
Parameter Option
Starting Mode
This must be programmed for Current Limit.
Current Limit
Ramp Time u
This programs the time period that the controller
will hold the fixed, reduced output voltage before
switching to full voltage.
0 to 30 s
Current Limit Level
This parameter provides adjustability for the
reduced output voltage level provided to the motor.
50 to 600% full load current
Kickstart Time
A boost of current is provided to the motor for the
programmed time period.
0.0 to 2.0 s
Kickstart Level
Adjusts the amount of current applied to the motor
during the kickstart time.
0 to 90/% locked rotor torque
u If the controller senses that the motor has reached full speed before completing the Current
Limit Start, it will automatically switch to providing full voltage to the motor.
