Rockwell Automation 1560E SMC Flex Smart Motor Controller - Manual (Page 167)

Specifications A-3
1560E-UM050B-EN-P - June 2013
Table A.1 – Specifications (cont.)
Environmental Ratings
UL/CSA/NEMA IEC
Operating Temperature Range 0°C to 40°C (32°F to 104°F)
Storage and Transportation Temperature Range -20°C to +75°C (-4°F to 149°F)
Altitude 0 - 1000 meters (3,300 feet) without derating v
Humidity 5% to 95% (non condensing)
Pollution Degree 2
Seismic (UBCRating) u 1, 2, 3, 4
u Some units may require special bracing. Contact factory for more information.
v Starter Deratings are in Table A.2.
Table A.3 – Area Available for Cable Entry/Exit
Top Bottom Structure
Code
Voltage
Line Load Line Load
14.60 2300 – 4160 V
5.68 X 9.00
(144 X 229)
Combined with line
5.68 X 9.00
(144 X 229)
Combined with line
14.62 6900 V
5.68 X 12.55
(144 X 319)
Combined with line
5.68 X 12.55
(144 X 319)
Combined with line
14.64 All
5.68 X 12.55
(144 X 319)
Combined with line
5.68 X 12.55
(144 X 319)
Combined with line
14.70 2300 – 4160 V
5.68 X 5.68
(144 X 144)
5.68 X 9.00
(144 X 229)
5.68 X 9.00
(144 X 229)
5.68 X 9.00
(144 X 229)
14.72 6900 V
5.68 X 9.00
(144 X 229)
5.68 X 9.00
(144 X 229)
5.68 X 5.68
(144 X 144)
5.68 X 9.00
(144 X 229)
14.74 2300 – 4160 V
5.68 X 9.00
(144 X 229)
5.68 X 9.00
(144 X 229)
5.68 X 9.00
(144 X 229)
5.68 X 9.00
(144 X 229)
14.76 All
5.68 X 9.00
(144 X 229)
7.25 X 15.88
(184 X 403)
5.68 X 9.00
(144 X 229)
7.25 X 15.88
(184 X 403)
Dimensions are in inches (mm).
Table A.2 – Altitude Derating
Power Cell Rating
Altitude Range
180 A 360 A 600 A
Reduce B.I.L.
Withstand Rating By:
Reduce Max. Continuous Current Rating By: 1000 to 2000 m
(3,300 to 6,600 ft.)
5 A 10 A 15 A
6.0 kV
2001 to 3000 m
(6,601 to 9900 ft.)
10 A 20 A 30 A 12.0 kV
3001 to 4000 m
(9,901 to 13,200 ft.)
15 A 30 A 45 A 18.0 kV
4001 to 5000 m
(13,201 to 16,500 ft.)
20 A 40 A 60 A 24.0 kV
