Table B.1 – Parameter List (cont.)
Group
Parameter Description
Parameter
Number
Units
Min / Max
Default
Settings
User
Settings
Stop Mode
32
Disable
Soft Stop
Linear Speed
SMB
Accu-Stop
Disable
Basic Set Up
Stop Time
33
SEC
0…120
0
Basic Set Up/Accu-Stop
Braking Current
35
% FLC
0…400
0
Slow Speed Sel
39
SS Low
SS High
SS High
Slow Speed Dir
40
SS FWD
SS REV
SS FWD
Slow Speed Cur
41
% FLC
0…450
0
Preset SS/Accu-Stop
Slow Running Cur
42
% FLC
0…450
0
Accu-Stop
Stopping Current
43
% FLC
0…400
0
Overload Class
44
Disable
Class 10
Class 15
Class 20
Class 30
Disable
Service Factor
45
0.01…1.99
1.15
Motor FLC
46
A
1.0…1000.0
1.0
Basic Set Up /
Overload
Overload Reset
47
Manual
Manual
Overload
Overload A Lvl
50
% MTU
0…100
0
Underload F Lvl
51
% FLC
0…99
0
Underload F Dly
52
SEC
0…99
0
Underload A Lvl
53
% FLC
0…99
0
Underload
Underload A Dly
54
SEC
0…99
0
Undervolt F Lvl
55
% V
0…99
0
Undervolt F Dly
56
SEC
0…99
0
Undervolt A Lvl
57
% V
0…99
0
Undervoltage
Undervolt A Dly
58
SEC
0…99
0
Overvolt F Lvl
59
% V
0…199
0
Overvolt F Dly
60
SEC
0.99
0
Overvolt A Lvl
61
% V
0…199
0
Overvoltage
Overvolt A Dly
62
SEC
0…99
0
Unbalance F Lvl
63
%
0…25
0
Unbalance F Dly
64
SEC
0…99
0
Unbalance A Lvl
65
%
0…25
0
Unbalance
Unbalance A Dly
66
SEC
0…99
0
Jam F Lvl
67
% FLC
0…1000
0
Jam F Dly
68
SEC
0…99
0
Jam A Lvl
69
% FLC
0…1000
0
Jam
Jam A Dly
70
SEC
0…99
0
Stall
Stall Delay
71
SEC
0.0…10.0
0
