Appendix
D
Spare Parts
1560E-UM050B-EN-P - June 2013
Table D.1
Bulletin 1503E • 1000-1500 Volt, 180/360 Amp, 6-device
Ì
Qty per controller Description Part Number
180 A
6 Individual SCR, 5STP04D5200 (matching not required) К Л 80156-815-61-R
360 A
6 Individual SCR, 5STP08G6500 (matching not required) К Л 80156-894-71-R
Common Components
Í 80165-898-52-R
3
SCR Gate Driver Board
(2 devices) Î 80165-898-55-R
1 IGDPS Board Î 80026-044-02-R
1 Voltage Sensing Module 81000-199-55-R
1 MV SMC Interface Circuit Board 80190-440-01-R
9 Snubber Resistor 80025-588-02-R
1000 V, 1.0 µF 80025-812-01-R
3
Snubber Capacitor
(4.5 kV peak) 1300-1500V, 0.68 µF 80025-812-02-R
3 Sharing Resistor, 32.5 k, 225 W, Two 2.5 k Tap 80025-753-01-R
2.5 m 80025-549-03-R
9 Fiber-optic Cable
5.0 m 80025-549-01-R
120 V AC (North America) 80187-051-51-R
1 Test Power Supply
Universal 80187-245-51-R
Ê If desired, a complete factory assembled SCR/heatsink assembly with snubber resistor and capacitor can be purchased rather than
individual SCRs. See table below for part numbers :
Qty per controller Description Part Number
3 180 Amp, 1000 Volt Controller 80157-863-55
3 360 Amp, 1000 Volt Controller 80157-863-56
3 180 Amp, 1300V and 1500V Controller 80157-863-54
3 360 Amp, 1300V and 1500V Controller 80157-863-52
Ë Requires a thin film of electrical joint compound between base and mounting surface. Available with SCR replacement parts
or separately as Part Number 80025-783-51.
Ì Reference only. 1503E – For OEM products, refer to OEM-supplied documentation for specific spare parts list.
1560/1562E are Allen-Bradley manufactured starters. Refer to Service Manual for specific spare parts list.
Í Used when options 13XG (Stop Control) or 13XB (Pump Control) are not provided.
Î Used when options 13XG (Stop Control) or 13XB (Pump Control) are provided.
