6-4 Options
1560E-UM050B-EN-P - June 2013
Option Parameter Range
Braking Control Ë
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Braking Control
SMB Smart
Motor Braking
Braking Current u
Allows the user to program the
intensity of the braking current
applied to the motor.
0…400% of full load current
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Braking Control
Slow Speed Select
Allows the user to program the slow
speed that best fits the application.
Low: 7%
High: 15%
Slow Accel Current
Allows the user to program the
required current to accelerate the
motor to slow speed operation.
0…450% of full load current
Slow Running Current
Allows the user to program the
required current to operate the
motor at slow speed operation.
0…400% of full load current
Braking Current u
Allows the user to program the
intensity of the braking current
applied to the motor.
0…400% of full load current
Accu-Stop
Stopping Current u
Allows the user to program the
intensity of the braking current
applied to the motor from slow
speed operation.
0…400% of full load current
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Braking Control
Slow Speed Select
Allows the user to program the slow
speed that best fits the application.
Low: 7%
High: 15%
Slow Accel Current
Allows the user to program the
required current to accelerate the
motor to slow speed operation.
0…450% of full load current
Slow Running Current
Allows the user to program the
required current to operate the
motor at the slow speed setting.
0…450% of full load current
Slow Speed
with Braking
Braking Current u
Allows the user to program the
intensity of the braking current
applied to the motor.
0…400% of full load current
u All braking/stopping current settings in the range of 1…100% will provide 100% braking current to the motor.
Ë Braking Control is not offered for standard use in MV applications. Please consult factory for further assistance.
Programming Parameters
(cont.)
