Programming
Overview
This chapter provides a basic understanding of the programming keypad
built into the SMC-Flex controller. This chapter also describes programming
the controller by modifying the parameters.
Keypad Description
The keys found on the front of the SMC-Flex controller are described below.
Escape
Exit a menu, cancel a change to a parameter value,
or acknowledge a fault/alarm.
Select
Select a digit, select a bit, or enter edit mode in a
parameter screen.
Up/Down
Arrows Scroll through options increase/decrease a value,
or toggle a bit.
Enter
Enter a menu, enter edit mode in a parameter screen,
or save a change to a parameter value.
Note: For ease of programming values, after using the Enter key to edit,
use the Sel key to jump to the digit that needs to be modified, then
use the arrow keys to scroll through the digits.
Programming Menu
Parameters are organized in a three-level menu structure for
straightforward programming. Figure 4.1 details the programming menu
structure and the three-level hierarchy.
In order to change parameters, the controller must be in the STOP mode,
and the control voltage must be present.
Chapter
4
1560E-UM050B-EN-P - June 2013
Esc Esc
Sel Sel
