4-4 Programming
1560E-UM050B-EN-P - June 2013
Programming Menu (cont.)
Table 4.A
Parameter Linear List
Parameter No. Description Parameter No. Description Parameter No. Description
1 Volts Phase A-B 40 Slow Speed Dir 79 PTC Enable
2 Volts Phase B-C 41 Slow Speed Cur 80 Phase Reversal
3 Volts Phase C-A 42 Slow Running Cur 81 Starts per Hour
4 Current Phase A 43 Stopping Current 82 Restart Attempts
5 Current Phase B 44 Overload Class 83 Restart Delay
6 Current Phase C 45 Service Factor 84 Factory Use
7 Watt Meter 46 Motor FLC 85 Factory Use
8 Kilowatt Hours 47 Overload Reset 86 Factory Use
9 Elapsed Time 48 Factory Use 87 Logic Mask
10 Meter Reset 49 Factory Use 88 Data In A1
11 Power Factor 50 Overload A Lvl 89 Data In A2
12 Mtr Therm Usage 51 Underload F Lvl 90 Data In B1
13 Motor Speed 52 Underload F Dly 91 Data In B2
14 SMC Option 53 Underload A Lvl 92 Data In C1
15 Motor Connection 54 Underload A Dly 93 Data In C2
16 Line Voltage 55 Undervolt F Lvl 91 Data In D1
17 Starting Mode 56 Undervolt F Dly 95 Data In D2
18 Ramp Time 57 Undervolt A Lvl 96 Data Out A1
19 Initial Torque 58 Undervolt A Dly 97 Data Out A2
20 Cur Limit Level 59 Overvolt F Lvl 98 Data Out B1
21 Torque Limit 60 Overvolt F Dly 99 Data Out B2
22 Kickstart Time 61 Overvolt A Lvl 100 Data Out C1
23 Kickstart Level 62 Overvolt A Dly 101 Data Out C2
24 Option 2 Input 63 Unbalance F Lvl 102 Data Out D1
25 Starting Mode 2 64 Unbalance F Dly 103 Data Out D1
26 Ramp Time 2 65 Unbalance A Lvl 104 Motor ID
27 Initial Torque 2 66 Unbalance A Dly 105 CT Ratio
28 Cur Limit Level 2 67 Jam F Lvl 106 MV Ratio
29 Torque Limit 2 68 Jam F Dly 107 Aux1 Config
30 Kickstart Time 2 69 Jam A Lvl 108 Fault Contact
31 Kickstart Level 2 70 Jam A Dly 109 Alarm Contact
32 Stop Mode 71 Stall Delay 110 Aux2 Config
33 Stop Time 72 Gnd Flt Enable 111 Language
34 Factory Use 73 Gnd Flt Level 112 Factory Use
35 Braking Current 74 Gnd Flt Delay 113 Factory Use
36 Factory Use 75 Gnd Flt Inh Time 114 Factory Use
37 Factory Use 76 Gnd Flt A Enable 115 Parameter Mgmt
38 Factory Use 77 Gnd Flt A Lvl 116 Backspin Timer
39 Slow Speed Sel 78 Gnd Flt A Dly 117 Factory Use
