D-6
Spare Parts
1560E-UM050B-EN-P - June 2013
Table D.6
Bulletin 1503E, 1560E, 1562E • 5500/6900 Volt, 180/360 Amp, 18-device
Í
Qty per controller
Description
Part Number
180 A
6
180A : Matched Set 3 SCRs DCR820 or 5STP03D6500 uË
80156-893-73-R
360 A
6
360A : Matched Set 3 SCRs DCR1020 or 5STP08G6500 uË
80156-894-73-R
Common Components
Î
80165-898-52-R
9
SCR Gate Driver Board
(2 devices)
Ï
80165-898-55-R
3
IGDPS Board Ï
80026-044-03-R
1
Voltage Sensing Module
81000-199-55-R
1
MV SMC Interface Circuit Board
80190-440-01-R
9
Snubber Resistor
80025-760-02-R
9
Snubber Capacitor 0.68 µF
80025-812-02-R
9
Sharing Resistor 32.5K, 225W
80025-753-01-R
2.5 m
80025-549-03-R
21
Fiber-optic Cable
5.0 m
80025-549-01-R
2
Bridge Rectifier Ð
24808-451-01-R
120 V
80145-581-02-R
2
MOV Ð
230 V
80145-581-07
120V AC (North America)
80187-051-51-R
1
Test Power Supply
Universal
80187-245-51-R
6
Voltage Divider Resistors, 74K 100W
80025-588-05-R
110/120 V AC
80154-991-59-R
1
Contactor Relay Control
Panel Ð
220/230 V AC
80187-226-52
3
Power Fuses w
Consult Engineering Data
2
CPT Primary Fuses w
Consult Engineering Data
1
LV Fuses
Consult Engineering Data
3
Heater Elements w
Consult Engineering Data
2
20 Amp Contact Cartridge for Isolation Switch Auxiliary w
700-CPM
3
1-pole Blade Assembly (400 Amp) w
80145-566-51-R
Special Lubricant (for Blade Assembly, 400 Amp)
80158-357-51-R
u
If desired, a complete factory assembled SCR/heatsink assembly can be purchased rather than individual SCRs.
See table below for part numbers :
Qty per controller
Description
Part Number
3
180 Amp, 6900 Volt Controller
80187-277-51
3
360 Amp, 6900 Volt Controller
80187-277-52
v
Requires a thin film of electrical joint compound between base and mounting surface. Available with SCR replacement parts
or separately as Part Number 80025-783-51.
w
1562E only.
Í
Reference only. 1503E – For OEM products, refer to OEM-supplied documentation for specific spare parts list.
1560/1562E are Allen-Bradley manufactured starters. Refer to Service Manual for specific spare parts list.
Î
Used when options 13XG (Stop Control) or 13XB (Pump Control) are not provided.
Ï
Used when options 13XG (Stop Control) or 13XB (Pump Control) are provided.
Ð
Not provided if IntelliVAC is used (refer to Publication 1503-UM051B-EN-P for spare part information on IntelliVAC).
