34
Rockwell Automation Publication 1413-UM001D-EN-P - November 2010
Chapter 3 Configuration
2.
Press the Enter key to edit the parameter.
3.
Use the up/down keys to change the value of the parameter.
4.
Press the Enter key to store the new value.
Esc key will discard the new value.
5.
Repeat steps 2…5 as needed.
TIP
If the data is protected or undefined, pressing the up/down key
scrolls to the next data element.
Table 9 - Control and Status Parameters
Address
Parameter
Unit
Description
Configurable Range
Default
PanelView
Component
Screen
N7:0
Capacitor Step 1 -
Measured Size
kVAR
Measured and averaged capacitor size for
each step
No
-
Configuration
N7:1
Capacitor Step 2 -
Measured Size
kVAR
No
-
Configuration
N7:2
Capacitor Step 3 -
Measured Size
kVAR
No
-
Configuration
N7:3
Capacitor Step 4 -
Measured Size
kVAR
No
-
Configuration
N7:4
Capacitor Step 5 -
Measured Size
kVAR
No
-
Configuration
N7:5
Capacitor Step 6 -
Measured Size
kVAR
No
-
Configuration
N7:6
Capacitor Step 7 -
Measured Size
kVAR
No
-
Configuration
N7:7
Capacitor Step 8 -
Measured Size
kVAR
No
-
Configuration
N7:8
Capacitor Step 9 -
Measured Size
kVAR
No
-
Configuration
N7:9
Capacitor Step 10 -
Measured Size
kVAR
No
-
Configuration
