Rockwell Automation Publication 1500-UM055G-EN-P - May 2013

69

Chapter

6

Spare Parts

The following list of spare parts is valid for typical Bulletin 1512 and 1512BT
units. Please contact your local Rockwell Automation office to ensure that the
following part numbers are valid for your system.

Bulletin 1512 and
1512BT Units Parts List

Table 3 - Spare Parts List

(5) For starters with electro-mechanical control.
(6) For starters with IntelliVAC Plus control.

For 400A contactor spare parts, refer to publication

1502-UM050_-EN-P

or Publication

1502-UM052_-EN-P

.

Part Number

Description

Recommended Stocking Quantity

80154-991-59

LV Control Panel

(2)(5)

(Electrically Held)

(2) The following is included with the LV Control Panel: CR1 relay, CR2 relay, rectifier, MOV assembly, test switch, test plug. Note: For

mechanical latch assemblies, an additional CR1 relay is substituted for the CR2 relay.

1

80154-991-61

LV Control Panel

(2)(5)

(Mechanical Latch)

1

1503VC-BMC5

IntelliVAC (Electrically Held and Mechanical Latch)

(4)

1

1503VC-BMC5-EM1

IntelliVAC Plus (Electrically Held and Mechanical Latch)

(6)

80174-902-14-R

Internal IntelliVAC fuse – 6.3A, 250 V (Littlefuse 21506.3)

(3)

(3) For starters with IntelliVAC control.

1

Engineering Data

(1)

(1) Consult spare parts list in service manuals that are provided following delivery of equipment.

Power Fuses

(4)(6)

(4) Power fuses are R rated for motor loads or E rated for non-motor loads. Power fuses are sized to the motor or transformer load data

provided at the time the starter is ordered. Refer to dimensional drawings for specific fuse type and size. Bolt-on or clip-on fuses are
available for various load sizes. Contact Rockwell Automation for details.

3

Engineering Data

(1)

Primary Fuses (CPT/PT)

2

Engineering Data

(1)

LV Control Circuit Fuses

2

Engineering Data

(1)

Heater Elements (if used)

3

40266-515-03

20 Amp Isolation Switch Auxiliary Contact Cartridge (700 CPM)

2

80178-707-53

Isolation Switch Blade Assembly 400A

3

80158-357-51

Nyogel 759G Lubricant

3

RU-8216

Dow Corning 55 O-ring Lubricant

1

80144-491-02

Fuse Extractor (For clip-on fuses only)

1
