Rockwell Automation 7000 DPI Wireless Interface Module - Manual (Page 37)

Configuring the WIM 3-15
2. In the text box, enter the desired name (for example, Pump 1) and
click Apply. Then click Close to close the WIM properties screen.
3. For the entered name to be recognized on the network, either reset
the WIM or power cycle the drive. Then re-establish wireless
communication between the WIM and the desktop or laptop
computer.
TIP: When using DriveExplorer version 5.01 or higher, you can also
name the WIM with this alternate method:
A. With the DriveExplorer/DriveExplorer Lite Menu Tree window
( Figure 3.25 ) displayed, select the “20-WIM-Nx Wireless Module”
in the tree view to display the WIM Product Window ( Figure 3.27 ) in
the right pane.
Figure 3.27 WIM Product Window
B. Click the gray “20-WIM-Nx” title header in the WIM Product
Window to display a name entry text box. Enter the desired name
(for example, Pump 1) and click Apply.
