Chapter
3
Configuring the WIM
Chapter 3 provides information about configuring the WIM.
For a list of parameters, refer to Appendix B , WIM Parameters . For
definitions of terms in this chapter, refer to the Glossary .
The WIM stores parameters and other information in its own
Non-Volatile Storage (NVS). You must, therefore, access the WIM to
view and edit its parameters. The following table lists tools that you can
use to access the WIM and edit its parameters.
Topic Page
Configuration Tools 3-1
Using Pocket DriveExplorer for Pocket PC 3-2
Using DriveExplorer/DriveExplorer Lite 3-10
Using DriveExecutive 3-16
Setting the Fault Action 3-24
Enabling and Setting the Security Mode 3-25
Resetting the WIM 3-26
TIP: The WIM is provided ready for use. It is only necessary to
configure the WIM if you want to:
• Change the default setting (0 = Fault) for:
– Parameter 02 - [Comm Flt Action] for DPI products
– Parameter 04 - [Comm Flt Action] for SCANport products
• Enable the security mode using:
– Parameters 03 - [Security Mode] and 04 - [Security PIN] for
DPI products
– Parameters 02 - [Security Mode] and 03 - [Security PIN] for
SCANport products
Configuration Tools
Device Type Tool Refer to…
Pocket PC Pocket DriveExplorer for Pocket PC (version 1.01 or higher) Page 3-2
Laptop or
Desktop
Computer DriveExplorer software (version 4.04 or higher) Page 3-10
DriveExecutive software (version 3.01 or higher) Page 3-16
PowerFlex HIM —
