[ Care and Use ManUal ]
Protein-Pak HR Ion-Exchanged Glass Columns 10
• Solvents expand with increasing temperature. To protect your column
during storage or shipment, a bellows is installed prior to shipment to
allow for this expansion.
CAUTION: A temperature increase of as little as 20 °C (68 °F) may
destroy a column with tightly-closed end caps. Install the bellows
any time the column may be exposed to drastic temperature changes
during storage or shipment.
V. orderIng 1nforMatIon
Protein-Pak HR Ion-Exchange Glass Columns
Advanced Purification (AP) Glass Columns for Protein
Purifications
Advanced Purification (AP) Glass Column Accessories and
Spare Parts
Ion-Exchange Particle Pore
Packing Type Size Size Dimension Part No.
Protein-Pak Q 8HR Polymeric strong 8 µm 1000Å 5 x 50 mm WAT039575
anion exchanger 5 x 100 mm WAT039630
1 0 x 100 mm WAT035980
Protein-Pak Q 15HR Polymeric strong 15 µm 1000Å 5 x 50 mm WAT039782
anion exchanger 10 x 100 mm WAT037663
Protein-Pak DEAE 8HR Polymeric weak 8 µm 1000Å 5 x 50 mm WAT039791
anion exchanger 5 x 100 mm WAT039783
10 x 100 mm WAT035650
Protein-Pak DEAE 15HR Polymeric weak 15 µm 1000Å 5 x 50 mm WAT039780
anion exchanger 5 x 100 mm WAT039786
10 x 100 mm WAT038564
Protein-Pak SP 8HR Polymeric strong 8 µm 1000Å 5 x 50 mm WAT039570
cation exchanger 5 x 100 mm WAT039625
10 x 100 mm WAT035655
Protein-Pak SP 15HR Polymeric strong 15 µm 1000Å 10 x 100 mm WAT038567
cation exchanger
Protein-Pak CM 8HR Polymeric weak 8 µm 1000Å 5 x 50 mm WAT039790
cation exchanger 5 x 100 mm WAT039785
10 x 100 mm WAT035970
Protein-Pak CM 15HR Polymeric weak 15 µm 1000Å 5 x 50 mm WAT039787
cation exchanger
Note: Additional custom column dimensions are available.
Approximate Protein Binding Capacity per Prepacked Column*
Protein-Pak HR Packing
Prepacked Column Q** DEAE** SP*** CM***
5 x 50 mm 60 mg 40 mg 40 mg 25 mg
5 x 100 mm 130 mg 150 mg 80 mg 45 mg
10 x 100 mm 500 mg 300 mg 300 mg 180 mg
Additional connectors and fitting are available.
Column Bed Volume Flow Rate Pressure Rating
Dimension (mL) (mL/min) (psi/MPa) Part No.
5 x 50 mm 0.8-1.2 0-4 1500 psi/10 MPa WAT064-01
5 x 100 mm 1.8-2.2 0-4 1500 psi/10 MPa WAT064-02
10 x 100 mm 5-8 0-4 1500 psi/10 MPa WAT021901
10 x 200 mm 13-16 0-4 1500 psi/10 MPa WAT021902
10 x 300 mm 21-24 0-4 1500 psi/10 MPa WAT021903
10 x 600 mm 45-48 0-4 1500 psi/10 MPa WAT021906
20 x 100 mm 22-31 4-16 1000 psi/6.8 MPa WAT027501
20 x 200 mm 53-62 4-16 1000 psi/6.8 MPa WAT027502
20 x 300 mm 85-94 4-16 1000 psi/6.8 MPa WAT027503
20 x 600 mm 179-188 4-16 1000 psi/6.8 MPa WAT027506
50 x 100 mm 137-196 16-100 500 psi/3.4 MPa WAT023331
50 x 200 mm 333-392 16-100 500 psi/3.4 MPa WAT023332
50 x 300 mm 530-589 16-100 500 psi/3.4 MPa WAT023333
50 x 600 mm 1118-1177 16-100 500 psi/3.4 MPa WAT023336
AP Minicolumn Accessories and Spare Parts
Description Column Dimensions Part No.
Glass Tube 5 x 50 mm WAT038802
5 x 100 mm WAT038803
Column Jacket 5 x 50 mm WAT038804
5 x 100 mm WAT038805
Filters, 10/pkg WAT038806
O-rings, 13/pkg WAT038807
(includes 10 inlet/outlet and 3 funnel)
AP-1 Column Accessories and Spare Parts
Description Column Dimensions Part No.
Glass tube 10 x 100 mm WAT021992
10 x 200 mm WAT022033
10 x 300 mm WAT022034
10 x 600 mm WAT022035
Plastic shield 10 x 100 mm WAT021927
10 x 200 mm WAT021945
10 x 300 mm WAT021946
10 x 600 mm WAT021947
O-rings, 5/pkg WAT021907
Filters, 10/pkg WAT021910
Replacement tubing (Tefzel) WAT021950
1/16 inch o.d. x 0.009 inch i.d. x 10 feet
(1.6 mm o.d. x 0.23 mm i.d. x 3 m)
