XSelect CSH XP 2.5 µm Columns 8
[ CARE AND USE MANUAL ]
Figure 5: eCord Intelligent Chip.
At the time of manufacture, information such as the performance test
chromatogram, column manufacturing QC data and Certificates of
Analysis is downloaded onto the eCord. This information may then be
accessed via the ACQUITY UPLC console once the column is installed.
b. Installation
The eCord can be read by connecting the yellow fob to the reader/
writer located on the right-hand side of the ACQUITY UPLC Column
heater module. Once the eCord is connected to the magnetic catch on
the column heater, column identification and overall column usage
information can be accessed.
Figure 6: Installing the eCord Intelligent Chip.
c. Manufacturing
The eCord provides the user with the Batch Certificate of Analysis and
Performance Test Chromatogram.
Figure 7: Manufacturing results stored on an eCord.
