IP Camera User’s Manual
|
 Broadband and router sharing Internet access mode (dynamic obtainment of extranet
IP address mode) like ADSL and so on;
For dial-up access with router, see below picture for the network topology:
Fig 91
Users can set up DDNS domain name service at the same time, fill the username and password
which were applied in the DDNS server into the DDNS setting item, then implement port mapping from
the router. The router determines and points to the IP camera that need to be visited according to
different ports, long-distance Internet user can visit the IP camera on the network via domain name
directly.
Please refer to [Appendix 4] for DDNS settings. Log in IE and enter the domain name and port
number, if it is the default port number “80”, users do not enter the port number. For example: http://
MyIPC.no-ip.org:2318.
 PPPoE dial-up access
For IP camera dial-up access, see below picture for the network topology:
Fig 92
Setup steps:
Step 1: Log in IP camera via crossover cable direct connection.
Step 2: Set PPPoE parameters. (For details, please refer to [PPPOE Configure])
Step 3: Connect IP camera to Internet.
Step 4: If DDNS service is successfully set for the device, the device can be visited via entering
domain name into IE browser.
