Talos Security BC960 - Manual

BC960 Color Camera
Talos Weatherproof IR Color Camera
Specification
Packing List
No Name Model Number
2.
User Guide BC960 1
1.
Weatherproof IR Color Camera BC960 1
Franchiser：
Notes: Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Model BC960
Pick up Element 1/3" SONY Super HAD CCD II
Effective Picture Elements
(H×V)
NTSC:976(H)×494(V),PAL:976(H)x582(V)
Horizontal Resolution 700TV Line
Minimum Illumination 0.001 Lux/F1.2
S/N Ratio More than 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
IR Distance 20 Meters (with ￠5X24PCS Infrared LED)
IR Status Under 10Lux by CDS
IR Power On CDS AUTO Control
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/350mA
Lens Board Lens 3.6mm/F2.0
Dimension (mm) 175(W)x69(H)x55(D)
Weight (g) 830
Storage Temperature -30~+60℃ RH95% MAX
Operating Temperature -10~+50℃ RH95% MAX
