IP Camera User’s Manual
|
5.4 OSD
The interface of OSD configure is shown in Fig 13:
Fig 13
[Time]: The system time of video channel. Enable this function to display system time at the top left of
image.
[Color]: User can choose different colors for the time. There are two colors to choose from black and
white.
[Position]: User can adjust the display position of system time.
[Text]: Enable this function to display channel name at the top left of image.
[Color]: User can choose different colors for the name. There are two colors to choose from black and
white.
[Position]: User can adjust the display position of channel name.
[Text]: The name of video channel, it supports 30 English characters or 20 Chinese words at
maximum. Click text box to self-define the channel name.
Click button to save the setting; when the setting is not saved, click
button to return to the previously saved parameters; when the setting has been saved, click
button to query whether the setting is successful.
5.5 Privacy Regional
After entering the privacy regional interface, click button at the center of
interface to enter the Shelter Area window, refer to Fig 14:
