Talos Security BD700 - Manual

BD700 Color Camera
Talos Vandalproof IR Dome Color Camera
Specification
Packing List
No Name Model Number
2.
User Guide
BD700
1
1. Vandalproof
IR Dome Color Camera
BD700 1
Franchiser：
Notes: Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Model BD700
Pick up Element 1/3" SONY Super HAD CCD II
Effective Picture Elements
(H×V)
NTSC:976(H)×494(V) PAL:976(H)x582(V)
Horizontal Resolution 700 TV Line
0.001 Lux/F1.2
0Lux (with IR LED ON)
S/N Ratio More than 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/350mA
Lens Board Lens 3.6mm /F2.0
Dimension (mm) ￠ 94 x 69(H)
Weight (g) 400
Storage Temperature -30~+60℃ RH95% MAX
Operating Temperature -10~+50℃ RH95% MAX
Minimum Illumination
IR Distance 20 Meters (with ￠5X24 PCS Infrared LED)
