Talos Security BC960V - Manual

BC960V Color Camera
Talos Weatherproof IR Color Camera
Specification
Packing List
No Name Model Number
2.
User Guide BC960V 1
1.
Weatherproof IR Color Camera BC960V 1
Franchiser：
Notes: Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Model BC960V
Pick up Element 1/3" SONY Super HAD CCD II
Effective Picture Elements
(H×V)
NTSC:976(H)×494(V) PAL:976(H)x582(V)
Horizontal Resolution 700TV Line
Minimum Illumination
S/N Ratio More than 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
IR Distance 40 Meters (with ￠5X42 PCS Infrared LED)
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V（+/-10%)/500mA
Lens 2.8-12mm Manual Zoom Lens
Dimension (mm) 220(W)x80(H)x80(D)
Weight (g) 1100
Storage Temperature -30~+60℃ RH95% MAX
Operating Temperature -10~+50℃ RH95% MAX
0.001 Lux /F1.2
