IP Camera User’s Manual
|
5.7 PTZ Configure
The interface of PTZ configure is shown in Fig 16:
Fig 16
[PTZ configure]: When IP camera is connected to RS485 communication or control device (e.g. PTZ
decoder, dome camera), the parameters of PTZ need to be set according to the settings of the
communication device (address, protocol, baud rate, parity, data bit and stop bit), and the
corresponding protocol need to be downloaded.
Click button to save the setting; when the setting is not saved, click
button to return to the previously saved parameters; when the setting has been saved, click
button to query whether the setting is successful.
Notice
：Only when the parameters and protocol are correct, the add-on
communication device can be controlled.
5.8 Record Configure
The interface of record configure is shown in Fig 17:
