IP Camera User’s Manual
|
Fig 47 Fig 48
 Click “ ” and Device to edit setting information. For example, click “device 66” in “Device
List”, you could modify the settings of “device 66”.
 Click “ ” to delete the selected device. For example, click “device 64” in “Device List”, will
show notice like Fig 48 , select “OK”, and delete “device 64”.
7.3.4 Switch Channel
 Select the numbers showed in Area 3 in Figure 49 to switch channels; select Area 2 to switch
channel-group, and then select the numbers in this channel-group to switch the channels.
 Switch the channels within different devices:
If you want to switch to the channels on other devices, steps as below:
1) Press “ ” to stop or turn the playing video off;
2) Click “+” on display interface, like Area 1 in Fig 49, then access device list interface, like Fig
50:
Fig 49 Fig 50
3) Select the device which switched to, will show the channel list of this device, like Fig 51 as
below:
