26
Putting into Operation
For incubators with O
2
module:
► Attach the supplied CO
2
pressure hose
to the CO
2
gas bottle (pressure reducer)
and to the “CO2 In” connection on the
rear of the incubator with a hose clamp
( Fig. 13 , see also page 13 ).
► Attach (push on) the supplied N
2
pres-
sure hose to the N
2
gas bottle (pressure
reducer) and to the “N2 In” connection
on the rear of the incubator with a hose
clamp.
4.3 Oxygen calibration
(only for models with O
2
module)
Perform an O
2
calibration before putting
into operation (see page 57 ).
CO
2
N
2
„CO
2
In“
„N
2
In“
Fig. 13
Gas connection for incubators with O
2
mod-
ule
