System bus (CAN) for Lenze PLC devices

Configuration (CAN−AUX interface)

6−13

PLC−Systembus EN 2.0

6.11.3

Bus load by CAN−AUX

Via C2461 you can receive a percentage display of the extent to which the system bus is loaded by
the telegrams of the CAN−AUX interface.

Only valid telegrams are considered.

Each transmit and receive channel is evaluated separately.

Code

LCD

Possible settings

Information

Lenze

Selection

C2461 Load IN/OUT

{1 %}

100 System bus − bus load

(CAN−AUX)

Trouble−free operation demands
that the total bus load (all
connected devices) does not
exceed 80 %.

1 Message OUT

All sent

2 Message IN

All received

3 Message OUT1

Sent on CANaux_OUT1

4 Message OUT2

Sent on CANaux_OUT2

5 Message OUT3

Sent on CANaux_OUT3

6 Message POUT1

Sent on parameter data channel 1

7 Message POUT2

Sent on parameter data channel 2

8 Message IN1

Received from CANaux_IN1

9 Message IN2

Received from CANaux_IN2

10 Message IN3

Received from CANaux_IN3

11 Message PIN1

Received from parameter data
channel 1

12 Message PIN2

Received from parameter data
channel 2
