Synchronisation
Tip!
By means of the CAN_Synchronization SB, the internal time base of the PLC can be synchronised
with the arrival of the sync telegram.
Thus, the internal calculating processes (e. g. control−oriented processes) of the PLC can be
synchronised with the calculating processes of other nodes which can also process the sync
telegram.
Detailed information on the CAN_Synchronization SB can be found in chapter 7.7.
(
^ 7−23)
3.7.1
CAN sync response
The response to the reception of a sync telegram can be configured via C0366:
Code
LCD
Possible settings
IMPORTANT
Lenze
Selection
C0366 Sync response
1
CAN sync response
0
No response
No response
1
Response to sync
PLC responds to a sync telegram
by sending the CAN1_OUT object.
3.7.2
CAN sync identifiers
The transmission or reception identifiers of the sync telegram can be configured via C0367/C0368:
Code
LCD
Possible settings
IMPORTANT
Lenze
Selection
C0367 Sync Rx Id
128
1
{1}
256 CAN sync Rx identifier
Receive identifier of the sync
telegram
C0368 Sync Tx Id
128
1
{1}
256 CAN sync Tx identifier
Transmit identifier of the sync
telegram
3.7.3
CAN sync Tx transmission cycle
The cycle time within which a sync telegram with the identifier set in C0368 is transmitted can be
configured via C0369:
Code
LCD
Possible settings
IMPORTANT
Lenze
Selection
C0369 Sync Tx time
0
0
{1}
65000
0 = Off
CAN sync transmission telegram
cycle
A sync telegram with the identifier
of C0368 is sent with the set cycle
time.
