System bus (CAN) for Lenze PLC devices
Configuration (FIF interface)
5−5
l
PLC−Systembus EN 2.0
·
Please note that the identifier of the telegram to be transmitted has to comply with the
identifier of the process data input object to be activated.
·
In the case of an individual address allocation, the identifier for the process data objects is
composed as follows:
Identifier + 384 ) value of C2454/x
x = subcode
·
Thus, for the process data objects identifiers in the range of 385 ... 896 can be allocated.
5.4.2 Display of the identifiers set
Via C2455 you can have the identifier displayed which is set for the process data objects.
·
C2455 is a display code, settings cannot be carried out via C2455.
Code LCD Possible settings Information
Lenze Selection
C2455
1
2
3
4
5
6
CAN Id
CAN1_IN Id
CAN1_OUT Id
CAN2_IN Id
CAN2_OUT Id
CAN3_IN Id
CAN3_OUT Id
g 385 {1} 896 System bus identifier
for the process data objects
FIF−CAN1_IN
FIF−CAN1_OUT
FIF−CAN2_IN
FIF−CAN2_OUT
FIF−CAN3_IN
FIF−CAN3_OUT
