System bus (CAN) for Lenze PLC devices
"CAN" system bus interface configuration
3−12
l
PLC−Systembus EN 2.0
3.12.3 Time−out when remote parameterisation is activated
If a time−out occurs during the remote parameterisation (gateway function) activated via C0370, the
system error message CE5 is output.
The response to this can be configured via C0603:
Code LCD Possible settings Information
Lenze Selection
C0603 MONIT CE5 3 System bus: Monitoring
configuration
Time−out when remote
parameterisation is activated
(C0370)
0 TRIP
2 Warning
3 Off
3.12.4 Response in the case of system bus fault messages
Overview of the system bus error sources registered by the PLC and of the possible settings for the
corresponding response:
Fault message Possible settings/response
Display Error
No. Meaning TRIP Message Warning Fault/QS
P Off Code
CE1 62 CAN1_IN communication error
(time monitoring can be set via C0357/1) ь − ь − • C0591
CE2 63 CAN2_IN communication error
(time monitoring can be set via C0357/2) ь − ь − • C0592
CE3 64 CAN3_IN communication error
(time monitoring can be set via C0357/3) ь − ь − • C0593
CE4 65 BUS−OFF state
(too many faulty telegrams were received) ь − ь − • C0595
CE5 66 CAN time−out
(gateway function C0370) ь − ь − • C0603
• Lenze setting
ü Possible
− Not possible
