System bus (CAN) for Lenze PLC devices

General information

2−13

PLC−Systembus EN 2.0

2.7.1.3

Addressing the parameter (index/subindex)

Identifier

Command

code

Index

Subindex

Data 1

Data 2

Data 3

Data 4

Low byte

High byte

The addressing of the parameter or of the Lenze code which is to be read or written is effected via
the index of the telegram:

Index + 24575 * Lenze code number

The value for the index is to be entered divided into a low and a high byte in the left−justified
Intel format (see example).

If a subcode is to be addressed, enter the number of the respective subcode in the subindex
of the telegram.

For codes without subcodes, the subindex always receives the value "0".

The index for Lenze codes is between 40C0

hex

(16576) and 5FFF

hex

(24575).

Lenze code

Index

dec

hex

C0000

24575

5FFF

...

C7999

16576

40C0

Tip!

For converting a code number to the corresponding index, the function L_FUNCodeIndexConv in
the LenzeDrive.lib function library is provided to you.

Example:

Subcode 1 of code C0168 (fault messages) is to be addressed:

Index + 24575 * 168 + 24407 + 5F57

hex

11bit

8 bytes user data

Identifier

Command

code

Index

Subindex

Data 1

Data 2

Data 3

Data 4

Low byte

High byte

hex

5Fhex

hex
