Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 83)

ASD Fan System
ITEM PART NO. QTY. DESCRIPTION
1 GR1976 12 Hex Flange Self Tapping Screw, ¼" x ¾"
2 GR1977 6 Fender Washer, ¼"
3 GR1965 2 Non-Flanged Outer Case
4 GR1979 2 Plastic Plug, 7∕16"
5 GR1966 2 Non-Flanged Inner Case
6 G11123 2 Hex Serrated Flange Cap Screw, ⅜"-16 x ¾"
7 GR1969 1 Backing Plate
8 GR1968 1 Cover Plate
9 G6801-06
GR1045 1
-
Elbow W/O-Ring, 90°, 9∕16"-18 Male JIC To O-Ring
O-Ring
10 G6801-10
GR1466 1
-
Elbow W/O-Ring, 90°, ⅞"-14 Male JIC To O-Ring
O-Ring
11 G11124 2 Hex Serrated Flange Cap Screw, ⅜"-16 x 1"
12 GA14574 1 Hydraulic Motor
13 G6801-12-10
GR1466 1
-
Elbow W/O-Ring, 90°. 11∕16"-12 Male JIC To ⅞"-14 O-Ring
O-Ring
14 GA15452 1 Overhung Load Adapter
15 GA14382 1 Fan Mount
16 G10621 15 Serrated Flange Nut, ¼"-20
17 GR1961 1 Bushing, ⅝"
18 GR1978 1 Plastic Plug, ¼"
19 G11409 15 Hex Serrated Flanged Cap Screw, ¼"-20 x 1"
20 GR1967 1 Screen
21 GD21300 1 Key Stock, 3∕16" x ¾"
22 GR2000 1 Hydraulic Motor Key
23 GA12812 - Hall Effect Adapter
24 GA14847
GD16324-01
GA9964
G1K248 1
-
-
-
Low Pressure Sensor (0-40 IN H
2
0) (Replaces GA14116)
Clear Plastic Tubing, ¼" x 45"
Strain Relief
3-Pin Female Connector Kit (Black), Includes: (3) 3-Pin Female Housings, (9) Pin
Contacts, (9) Seals
25 GR1736 1 Hose Barb, ⅛" Male NPT To Barb
26 GD21278 - Reducing Tee, 3∕16" x ⅛"
27 --- - See “Center Pivot” on page P119
28 GA10765
GR1777 2
-
Analog Vacuum Gauge W/Hose Barb
Hose Barb, 3∕16" x ⅛" NPT
29 GD15804
G10108
G10001 2
2
2 Mount
Lock Nut, ⅜"-16
Hex Head Cap Screw, ⅜"-16 x 1"
30 G11215 6 Hex Socket Head Cap Screw, No. 6-32 x ⅜", Grade 8
31 GD15849-02 1 Clear Tubing, 5∕16" O.D. x 3∕16" I.D. x 120"
32 GA10765
GR1777 1
-
Analog Vacuum Gauge W/Hose Barb
Hose Barb, ⅛" Male NPT To 3∕16" Barb
33 GA10799 1 Breather, ⅛" Male NPT
34 G11518
G10243 3
3 Hex Head Machine Screw, #10-24 x 1"
Washer, No. 10 SAE
35 GR2109 - Impeller
A GA14572 - ASD Fan Assembly (Non-Flanged) (Items 1-5, 7-8, 16, and 18-20)
B GR1960 - Hydraulic Motor Seal Kit
C GR2179 - Motor Seal Kit (Shaft)
Model 3600 M0236-02
Rev. 5/14 P80
