Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 148)

Two-Speed Point Row Clutch Wheel Module Extension
ITEM PART NO. QTY.
(Per Assy.)
DESCRIPTION
21 GA7336
GD7426
GD1026
G11387
G10229
G10047 1
-
-
-
-
-
Idler W/Bolt-On Sprockets
Sprocket, 12 Tooth
Sleeve, 13∕16" Long
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Head Cap Screw, ⅜"-16 x 1¾"
22 G10036
G10107
G10104 1
1
1 Hex Head Cap Screw, ⅝"-11 x 4"
Lock Nut, ⅝"-11
Hex Nut, ⅝"-11
23 G10595
G10108 1
1 Hex Head Cap Screw, ⅜"-16 x 10"
Lock Nut, ⅜"-16
24 G10496 2 External Inverted Snap Ring, 1½"
25 G11075 2 External Inverted Snap Ring, ⅞"
26 GD14432 1 Sleeve, 1¼"
27 GD14414
GD14413 1
-
Torsion Spring, R.H. (Used In L.H. Wrap Spring Wrench) (Shown)
Torsion Spring, L.H. (Used In R.H. Wrap Spring Wrench)
28 GD19344
GD19343 -
1
Release Collar, Gray, L.H. (Shown)
Release Collar, Blue, R.H.
29 GD14426 1 Tightener Shaft, 3⅜"
30 GD14431 1 Handle
31 G10235 2 Machine Bushing, ⅞", 14 Gauge
32 G11100
G10227
G11385 1
1
1 Hex Socket Button Head Cap Screw, ¼"-20 x ½", Grade 8
Lock Washer, ¼"
Flat Washer, ¼" SAE
33 G11078 1 Vinyl Cap
34 G10037
G11389
G10228
G10102 1
1
1
1 Hex Head Cap Screw, ½"-13 x 1¼"
Flat Washer, ½" SAE
Lock Washer, ½"
Hex Nut, ½"-13
35 GA7313 1 Sprocket Storage Rod
36 GD2558 2 Lynch Pin, ¼"
A G1K381
G1K380 -
1
Wrap Spring Wrench Replacement Kit, Gray Collar, L.H. (Items 24-33) (Shown)
Wrap Spring Wrench Replacement Kit, Blue Collar, R.H. (Items 24-33)
TM
M0236-02 Model 3600
P145 Rev. 11/11
