Kinze 3600 Lift and Rotate Planter Rev. 5/14 - Manual (Page 235)

Liquid Fertilizer Tanks, Saddles, Saddle Mounts, and Hoses
(Conventional)
ITEM PART NO. QTY. DESCRIPTION
1 GA14049
GA16428
GA16157
GR0513
GR0508
GR1941
G10096
1
1
1
1
2
1
1
Tank W/Lid and Fittings, 150 Gallon
Lid, 7" W/Vacuum Breaker
Vacuum Breaker
¾
" Polypropylene Fitting Assembly (Overflow Fitting, Nut, Bushing And O-Ring) (Top
And Bottom Of Tank)
1¼" Polypropylene Fitting Assembly (Nut, Bushing And O-Ring) (Bottom Of Tank)
Seal
Pipe Plug, ¾" NPT
2 G10626
G10674
G4602-04 1
1
1 Adapter, 1¼" NPT To Barb
Hose Clamp, No. 24
1¼" x 32' Black Helix Hose
3 GD11123
GD11124
G10901
G10485
G10674 4
2
4
4
1 Anchor
Strap, 84"
Lock Nut, ⅜"-16
Hex Head Tap Bolt, ⅜"-16 x 5"
Hose Clamp, No. 24
4 GA14112
G10004
G11091 1
2
2 Hose Guide
Hex Head Cap Screw, ⅜"-16 x 1¼"
Serrated Flange Nut, ⅜"-16
5 G10633
G10674
G4200-03
G4200-06 1
3
1
-
Tee, 1 ¼" Barb
Hose Clamp, No. 24
Hose, 1¼" x 32', 12 Row 30"
Hose, 1¼" x 40', 16 Row 30"
6 GD10110
GD1747
G10231
G10105 2
2
4
4 Mounting Angle (2 Per Tank)
U-Bolt, 5" x 7" x ¾"-10
Lock Washer, ¾"
Hex Nut, ¾"-10
7 G10626
G10674 3
3 Adapter, 1¼" NPT To Barb
Hose Clamp, No. 24
8 GA4976
GR1015
GR1016
GR1017
GR1018
GR1019 1
-
-
-
-
-
Shutoff Valve, 1¼" NPT
Body O-Ring
Stem O-Ring
Teflon Seat
Ball
Handle
9 G10887 1 Elbow, 90°, 1¼" Male NPT To Female
10 G10619 1 Close Nipple, 1¼" NPT
11 G10616 2 Reducing Bushing, 2" Male NPT To 1¼" Female
12 G10630
G10676
G4201-03 2
2
1 Elbow, 90°, 2" NPT To Barb
Hose Clamp, No. 36, Stainless Steel
Hose, 2" x 18', 12 and 16 Row
13 G10888 1 Tee, 2" Female NPT
14 GA2660 1 Shutoff Valve, 2" NPT
15 G10623 1 Close Nipple, 2" NPT
16 G10889 1 Elbow, 45°, 2" Male NPT To Female
17 GD3623 1 Adapter, 2" Male NPT To Cam Lock
18 GD3951 1 Dust Cap, 2" Cam Lock
19 GD1113
G10230
G10104 1
2
2 U-Bolt, 5" x 7" x ⅝"-11
Lock Washer, ⅝"
Hex Nut, ⅝"-11
20 GA7845 1 Quick Fill Mount, 2"
21 GA7133
GD1862
G10007
G10230
G10104 2
1
4
4
4 Tank Mount (2 Per Tank)
Pad, 8" x 14' (For Two 30" Tanks)
Hex Head Cap Screw, ⅝"-11 x 1½"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
22 GD20060
G10674 1
1 Hose Bracket
Hose Clamp, No. 24
Model 3600 M0236-02
